Detailed technical characteristics:
This learning system combines a modular design approach with computer data acquisition to introduce students to the fundamentals of electricity, such as direct current, alternating current, voltage, resistance, and Ohm's law.
It should cover the following topics:
-Learning how to solve DC and AC circuits using appropriate methods, such as impedance calculation and the
-AC circuit concepts: Sinusoidal wave, phase angle, phase shift, power, reactance, impedance
-AC circuit concepts: Sinusoidal wave, phase angle, phase shift, power, reactance, impedance
-DC circuit concepts: resistance, voltage, current, power, series vs. parallel
-Power concepts in AC circuits: active power, reactive power, apparent power, and power triangle
-Introduction to Ohm's Law
The trainer have the following:
-Three-module workstation (EMS)
-Set of laboratory safety cables,
-Dynamometer/four-quadrant power supply with manual and computer control,
-24 V AC power supply for wall mounting,
-Resistive load,
-Inductive load,
-Capacitive load,
DC Power Circuits (Workbook)
DC Power Circuits (Workbook (teacher))
Single-Phase AC Power Circuits (Workbook)
Single-Phase AC Power Circuits (Workbook (teacher))
Digital Multimeter
Laboratory Safety Cable Set
Transformer
Three-phase transformer bank
Power diodes
Rectifier and filter capacitors
Variable three-phase power supply
Power supply: 120-208V, 3F, 60 Hz.
The teaching bench have a total electrical power of no more than 2.4 kW. If a higher load is required, the necessary components and protections be used.
The necessary components and protections be used in order to ensure the safety of the property and the
A secure and adequate type of connection be provided.
The necessary integrated protections be in place as a safety measure.
The bench be modular.
Technical standards and norms that the product meet or exceed
The bench comply with certifications and technical standards that guarantee its safety, quality, and Educational relevance.
