3. Product component names and function introduction
3.1 Product main part
|
NO. |
Name |
Qty. |
|
1 |
Main workbench |
1 |
|
2 |
Power supply unit module |
6 |
3.2 Product module part
|
NO. |
Name |
Qty. |
|
1 |
230VAV socket power supply unit |
2 |
|
2 |
240VDC power supply unit |
1 |
|
3 |
24VAC power supply unit |
1 |
|
4 |
Three-phase power supply unit |
1 |
|
5 |
400VAC three-phase power supply unit |
1 |
3.3 Product accessorie
|
NO. |
Name |
Qty. |
|
1 |
4mm safety electrical cable 1m double ended black |
5 |
|
2 |
4mm safety electrical cable 1m double ended blue |
5 |
|
3 |
4mm safety electrical cable 1m double ended yellow |
5 |
|
4 |
4mm safety electrical cable 1 meter double ends double colors |
5 |
|
5 |
4mm safety electrical cable 1m double ended red |
5 |
|
6 |
4mm safety electrical cable 1m double ended green |
5 |
3.4 Product module introduction
1. Name: AC 230V power socket
Parameters: AC230V+N+T/50HZ
Purpose: Used to power AC 230V voltage adapter plug
2. Name: AC 24V power supply unit
Parameters: AC24V/5A-50HZ
Purpose: Used to power AC 24V power units
3. Name: DC 240V power supply unit
Parameters: DC240V/2A
Purpose: Used to supply power to DC 240V power units
4. Name: AC 400V three-phase five-wire power supply unit
Parameters: AC400V/50HZ
Purpose: Used to supply power to AC 400V power units
4. Product power-on test list (see the test guide for details)
(1) 230VAC power supply unit test
The unit outputs 230V AC voltage, has no separate control switch, and cannot be adjusted
(2) 24VAC power supply unit test
The unit outputs 24V AC voltage, has a separate control switch, and cannot be adjusted
(3) 240VDC power supply unit test
The unit outputs 24V AC voltage, has a separate control switch, and cannot be adjusted
(4) 400VAC power supply unit test
The unit outputs 24V AC voltage, has a separate control switch, and cannot be adjuste
