Electrical Circuit and AC/DC Measurement Bench Educational Equipment Didactique Materiels Smart Grid Training Equipment

Name: Electrical Circuit and AC/DC Measurement Bench Educational Equipment Didactique Materiels Smart Grid Training Equipment
Brand: Minrry.com
SKU: MR250116EE05
Availability: InStock
Rating: 5 (1 reviews)

Item No.: MR250116EE05

MR250116EE05 Electrical Circuit and AC/DC Measurement Bench Educational Equipment Didactique Materiels Smart Grid Training Equipment

INQUIRY

Description

MR250116EE05 Electrical Circuit and AC/DC Measurement Bench Educational Equipment Didactique Materiels Smart Grid Training Equipment

Detailed technical characteristics:
The trainer is geared toward current competency requirements, including the fundamentals of electricity(DC power circuits), single-phase and three-phase AC power circuits, power transformers, three-phase transformer banks, permanent magnet DC motors, three-phase rotating machines (induction machine and synchronous machine), and power factor correction.
The following topics should be covered:
AC and DC circuit concepts: resistance, Ohm's law, active and reactive power, phase angle, resolution of circuits, transformers.
Asynchronous machines: characteristics, operation as a brake/motor/eddy current generator, high-efficiency motors.
Synchronous machines: characteristics, operation as motor/generator, synchronization, voltage regulation, effort.
DC permanent magnet motor: characteristics, operation as a motor, operation as a generator.
Single-phase and three-phase transformers: relationships, windings, polarity, regulation, interconnections, configurations.
The following equipment be available:
Synchronous motor/generator
Three-phase transformer bank
Lead-acid battery bank
Toothed belt
Set of laboratory safety cables
Four-quadrant dynamometer/power supply with manual control
24 V AC wall-mount power supply, 120 V 60 Hz
Four-pole squirrel cage motor with thermistor
Resistive load
Inductive load
Capacitive load
Transformer
Permanent magnet DC motor
Synchronization module/three-phase contactor

You have the following work manuals:
DC circuits (Work manual)
DC circuits (Work manual (teacher))
Single-phase AC circuits (Workbook)
Single-phase AC circuits (Workbook (teacher))
Three-phase AC circuits (Workbook)
Three-phase AC circuits (Workbook (teacher))
Three-phase rotating machines (Workbook)
Three-phase rotating machines (Workbook (teacher))
Single-phase power transformers (Workbook)
Single-phase power transformers (Workbook (teacher))
Three-phase transformer banks (Workbook)
Three-phase transformer banks (Workbook (teacher))
Power factor correction (Workbook)
Power factor correction (Workbook (teacher))
Permanent magnet DC machine (Workbook (teacher))
Permanent magnet DC machine (Workbook)
List for performing exercises:
Digital multimeter
Workstation
DC motor/generator
Capacitor start motor
Universal motor
Conventional DC machines and universal motor (Workbook)
Conventional DC machines and universal motor (Workbook (teacher))
Single-phase induction motors (Workbook)
Single-phase induction motors (Workbook (teacher))
Multifunction computer with touch screen (includes monitor stand with articulated arm),
Variable three-phase power supply
Set of laboratory safety cables
Toothed belt
Storage shelves
Power supply: 120-208V, 3F, 60 Hz.
The teaching bench have a total electrical power of no more than 2.4 kW. If a higher load is required, the necessary components and protections be used.
The necessary components and protections be used in order to ensure the safety of the property and users.
A secure and adequate type of connection be provided.
The necessary integrated protections be in place as a safety measure.
The bench be modular.
Technical Standards and Regulations that the product meet or exceed
The bench comply with certifications and technical standards that guarantee its safety, quality, and Educational relevance.
