Description

MR719E Three-Phase Transformer 400V/230V 1kVA Vocational Training Tools and Equipment Industrial Training Equipment Electrical Skills Training

1. Equipment introduction
1.1 Overview
Transformers used in power systems for power transmission and distribution are collectively referred to as power transformers. According to the number of phases of a single transformer, power transformers can be divided into three-phase transformers and single-phase transformers. In three-phase power systems, three-phase transformers are generally used.
1.2 Features
The product is assembled with aluminum profiles and has a firm structure.
2. Technical parameters
Input power supply: AC 230V (Delta connection) / AC 400V (Star/Y connection)
Weight: 25 kg
Operating conditions: Ambient temperature -15°C to +45°C; relative humidity <75% (at 25°C)
Dimensions: 400 mm × 380 mm × 250 mm

3. Component list and detailed introduction
3.1 Main part:

No.	Name	Quantity
1	Power Input Terminal	1
2	Power Output Terminal	1
3	Grounding Terminal	1

3.2 Accessories

No.	Name	Quantity
1	Green 4mm electrical safety connection cable	4
2	Yellow 4mm electrical safety connection cable	4
3	Red 4mm electrical safety connection cable	4
4	Blue 4mm electrical safety connection cable	4

4. Experiment list
Experiment 1: Three-Phase Transformer Y-Connection No-Load Test
Experiment 2: Three-Phase Transformer Δ-Y Connection No-Load Test
Experiment 3: Three-Phase Transformer Y-Δ Connection No-Load Test
