Specific features
•Power supply: 220 volts
•Tank capacity: 120 liters
•Flow rate: 25 liters/minute
•Frequency: 60 Hertz
•Power: 5 kilovolts
•Suction accuracy: 0.85 bar
•Working accuracy: 50 to 70 bar
Additional features
With the following components:
•1 fixed displacement gear pump
•1 fixed displacement vane pump
•1 variable displacement vane pump
•1 fixed displacement piston pump
•1 variable displacement piston pump
•1 centrifugal pump (low pressure, high flow)
•1 leak-proof 3/8" male quick-connect distributor for pressures up to 3,000 PSI (4 return connections, 2 drain connections, 6 pressure connections for pump)
•1 tank with a capacity of 100-150 liters (level and temperature gauge)
•Suction filter
•Air filter and fill pre-filter
•Separation plate between suction and return pipes
•Acrylic side inspection window for internal viewing of the separation plate, suction filter, suction line, and return line
1 instrument control panel, 1 press, valve
Ball valve and flow control valve on the suction line of the gear pump for aeration and cavitation simulation
•2 electric motors, 5 HP power, 220 to 240 VAC, 60 Hz, three-phase, 1750 RPM rotation, flexible coupling with gear, IP 54 protection rating, 3/8" couplings and hoses up to 3000 psi
•Electrical control panel with total drive power of 5 kW, voltage of 220 to 240 VAC, 60 Hz, control voltage: 24 VDC, push-button panel for ON/OFF valve operation for system relief (venting) and emergency
•1 set of 3/8" hoses with quick-connect anti-leak couplings (10 hoses of 600 mm, 8 hoses
1000 mm hoses, 4 hoses 2000 mm)
•2 T-connections
•1 pressure relief valve
•1 bidirectional hydraulic motor
•1 4/3-way tandem center directional valve with detent lever
•1 sequence valve with integrated check valve
•1 valve reducing pressure pressure with integrated check valve
•1 simple check valve
•1 glycerin pressure gauge with a scale of 0-100 bar
•1 double-acting cylinder with a 38 mm diameter piston and 200 mm stroke.
•1 instrument control panel, 1 press, ball valve, and flow control valve on the suction line of the gear pump for simulating aeration and cavitation
• Equipment manual in physical and digital form
•Manual with steps for performing practical exercises on the different operations of the equipment
