Description

MR716E Group: Synchronous Motors Alternator Non Autoexicited Low Power 230V/400V + DC Coumpound Motor Educational Lab Equipment Demonstrational Equipment Electrical Installation Lab

1. Product Overview
1.1 Product Description
The stator of a DC compound-wound motor is equipped with two independent excitation windings: a series winding and a shunt winding. Combining these two excitation methods results in what is known as a compound-wound DC motor. The series winding consists of fewer turns of thicker wire and is connected in series with the rotor armature circuit, carrying the armature operating current; the shunt winding consists of many turns of thinner wire and is connected directly in parallel across the power supply, carrying a constant, low excitation current.
1.2 Product Features
High starting torque.
Good speed stability.
2. Technical Specifications
2.1 Technical Parameters
Power supply: DC 220V
2.2 Dimensions and Weight
Dimensions: 550mm × 235mm × 230mm
Weight: <20kg

3. Product Component Names and Functions
3.1 Main Unit

No.	Name	Quantity
1	Housing	2
2	Panel	2
3	Excitation power supply	1
4	Coupling	1

3.2 Product Accessories

No.	Name	Quantity
1	4mm electrical safety connection cable, 1m, Double-ended, Yellow	2
2	4mm electrical safety connection cable, 1m, Double-ended, Green	2
3	4mm electrical safety connection cable, 1m, Double-ended, Red	5
4	4mm electrical safety connection cable, 1m, Double-ended, Blue	2
5	4mm electrical safety connection cable, 1m, Double-ended, Black	5

4. List of Product Teaching Experiments (refer to the experiment manual for details)
(1) Familiarization with the Compound-Excited DC Motor
(2) Power generation operation experiment: Compound-excited DC motor coupled with a synchronous motor
